ARP IMPEX is a supplier and exporter of Siemens SIPROTEC 5 Compact 7SX800 Universal Protection Relays in India. We handle requirements for medium-voltage switchgear, feeder protection panels, industrial substations, motor protection, retrofit projects and replacement of existing numerical relays.

The Siemens 7SX800 is a compact multifunction protection relay used for feeders, distribution lines and small to medium-sized motors. It combines protection, circuit-breaker control, measurements, event recording and communication within one device.

The relay can be configured for different applications instead of using separate relay models for every protection requirement. Depending on the ordered function package, the 7SX800 can provide directional and non-directional overcurrent protection, earth-fault protection, motor protection, voltage and frequency protection, automatic reclosing and backup protection.

Its compact construction makes it useful for switchgear panels where available mounting space is limited. Different versions are available with varying binary inputs, output contacts and communication interfaces. Relay settings and engineering are carried out through Siemens DIGSI 5 software.

The 7SX800 can also communicate with SCADA and substation automation systems through serial or Ethernet interfaces. IEC 61850 is available on applicable configurations for projects requiring modern substation communication.

ARP IMPEX supplies Siemens SIPROTEC 5 Compact 7SX800 Relays for feeder protection, motor protection and medium-voltage switchgear applications. Share the complete Siemens article number for price and availability.

Technical Specifications

• Brand: Siemens
• Product family: SIPROTEC 5 Compact
• Model: 7SX800
• Product type: Universal numerical protection relay
• Main applications: Feeder, line, motor and backup protection
• Current inputs: Four CT inputs
• Voltage inputs: Four VT inputs
• Binary inputs and outputs depend on the selected hardware version
• Auxiliary supply: AC or DC, depending on the ordering code
• Display: Integrated front display
• Indication: Programmable LEDs
• Engineering software: Siemens DIGSI 5
• Local communication: Front service interface
• Remote communication: Serial or Ethernet, depending on the configuration
• IEC 61850: Available on applicable models
• Control functions: Circuit-breaker control and switchgear interlocking
• Logic: User-programmable control logic
• Recording: Fault, event and disturbance records
• Mounting: Suitable for compact switchgear and protection panels

The exact protection functions, binary contacts, communication ports and function package depend on the complete Siemens ordering code.

Main Protection Functions

• Depending on the selected configuration, the Siemens SIPROTEC 7SX800 can provide:
• Directional and non-directional phase overcurrent protection
• Directional and non-directional earth-fault protection
• Sensitive earth-fault protection
• Motor thermal and starting protection
• Undervoltage and overvoltage protection
• Underfrequency and overfrequency protection
• Automatic reclosing
• Load-shedding functions
• Circuit-breaker failure protection
• Trip-circuit supervision
• Backup protection for transformers and generators
• Programmable control and interlocking logic

The required functions are selected through the ordered relay configuration. The complete article number should therefore be checked before offering a replacement or project model.

Features

• Combines protection, control, measurement and monitoring in one relay
• Suitable for feeder, line, motor and backup protection applications
• Directional and non-directional protection options are available
• Supports phase overcurrent and earth-fault protection
• Motor functions can cover thermal overload and prolonged starting
• Voltage and frequency functions support power-management schemes
• Automatic reclosing is available for applicable feeder applications
• Programmable logic supports switchgear control and interlocking
• Different binary I/O versions suit basic and more complex panels
• Front display shows measurements, relay status and trip information
• Fault and disturbance records help investigate electrical trips
• DIGSI 5 supports configuration, settings and commissioning
• Serial communication can support existing SCADA systems
• IEC 61850 supports modern substation automation projects
• Compact size helps reduce panel-space requirements
• Suitable for new panels, retrofit projects and replacement requirements

Applications

Siemens SIPROTEC 5 Compact 7SX800 Universal Protection Relays are commonly used for:

Medium-voltage incoming feeders
Medium-voltage outgoing feeders
Radial distribution systems
Ring and parallel feeder networks
Cable feeder protection
Overhead-line protection
Industrial distribution substations
Utility substations
Small and medium-sized motor protection
Pump and compressor protection panels
Transformer backup protection
Generator backup protection
Busbar backup protection
Voltage and frequency monitoring
Underfrequency load-shedding systems
Renewable-energy feeder protection
Switchgear control and interlocking
Protection-panel retrofit projects
Replacement of older numerical relays

The Siemens 7SX800 is suitable for feeder protection, motor protection, medium-voltage switchgear and substation automation applications. IEC 61850 communication is available on applicable configurations.

Selecting the Correct Siemens 7SX800 Relay

The description “SIPROTEC 5 Compact 7SX800” does not identify a standard configuration. Models can differ by binary inputs and outputs, communication interfaces and enabled protection functions.

For an accurate quotation, share:

• Complete Siemens article number or MLFB
• Required quantity
• Destination country
• Communication requirement, where applicable

For replacement enquiries, also share clear photographs of the existing relay nameplate and rear terminal arrangement.

If the article number is unavailable, share the existing relay model and whether the requirement is for feeder, motor, voltage, frequency or backup protection.

Siemens SIPROTEC 5 Compact 7SX800 Supplier and Exporter in India

ARP IMPEX supplies Siemens SIPROTEC 5 Compact 7SX800 Universal Protection Relays for switchgear manufacturers, EPC contractors, panel builders, utilities and industrial maintenance companies.

We handle enquiries for:

• Siemens SIPROTEC 5 Compact 7SX800 Relays
• Universal feeder protection relays
• Directional overcurrent and earth-fault relays
• Motor protection relays for industrial applications
• Voltage and frequency protection relays
• Protection relays with serial communication
• SIPROTEC relays with IEC 61850
• Feeder protection-panel retrofit requirements
• Replacement Siemens numerical relays
• Industrial and utility substation projects

The Siemens SIPROTEC 7SX800 price depends on the complete article number, I/O arrangement, enabled functions, communication interface and ordered quantity.

Send the complete Siemens part number, required quantity and destination country for price, availability and export quotation.
