Schneider VAMP 210 Protection and Control Relay for Power Systems
Schneider VAMP 210 Protection and Control Relay Suppliers,Exporters in India
Schneider VAMP 210 Protection and Control Relay is used for the protection and monitoring of small and medium-sized generators, including generator systems rated up to approximately 100 MW. It covers the main protection duties required in generator panels, such as overcurrent, earth fault, voltage, frequency and current unbalance protection.
The relay can be used with solidly earthed, high-resistance earthed and low-resistance earthed generator systems. Optional arc flash protection is available for installations where fast fault detection inside the switchgear is required.
VAMP 210 also records events, fault values and disturbance data. This gives maintenance teams useful information when checking the cause of a trip, shutdown or abnormal generator condition. For projects requiring generator differential protection, the VAMP 210 can be used together with the VAMP 265 relay.
Communication options depend on the selected relay version and may include IEC 61850, Modbus, DNP3, IEC 60870 and Profibus. Settings and relay records can be accessed through VAMPSET software.
Specifications
- Product Name: Schneider VAMP 210 Protection and Control Relay
- Series: VAMP 200 Series
- Relay Type: Numerical Generator Protection Relay
- Main Application: Small and medium-sized generator protection
- Typical Generator Rating: Up to approximately 100 MW
- Earthing Systems: Solidly earthed, high-resistance earthed and low-resistance earthed systems
- Protection Functions: Overcurrent, earth fault, voltage, frequency, current unbalance and programmable protection stages
- Arc Protection: Optional
- Event Recording: Up to 2,000 event records
- Fault Records: Fault value registration and disturbance recording
- Measurements: Current, voltage, frequency, active power, reactive power, energy and demand
- Power Quality Functions: Harmonics up to the 15th order, THD, voltage sag and voltage swell
- Control Functions: Local and remote control of switching devices
- Communication: IEC 61850, Modbus TCP, Modbus RTU, DNP3, IEC 60870-5-101, IEC 60870-5-103, Profibus DP and SPA-bus, depending on configuration
- Configuration Software: VAMPSET
- Mounting: Panel mounting
Features
- Protection for small and medium-sized generators
- Supports different generator earthing arrangements
- Overcurrent and earth fault protection
- Voltage and frequency supervision
- Current imbalance and negative sequence monitoring
- Optional arc flash protection
- Event and disturbance recording
- Electrical measurement and power quality monitoring
- Local and remote breaker control
- IEC 61850 communication with GOOSE on applicable versions
- Multiple communication protocol options
- Configuration and commissioning through VAMPSET
- Can be combined with VAMP 265 for generator differential protection
Applications
- Generator protection panels
- Captive power plants
- Utility power generation systems
- Diesel generator installations
- Gas turbine generators
- Hydro power plants
- Cogeneration plants
- Marine generator systems
- Offshore power installations
- Cement and steel plants
- Oil and gas facilities
- Mining operations
- Process industry power systems
- Generator switchgear replacement projects
- Schneider VAMP 210 Relay Supplier and Exporter
We supply and export Schneider VAMP 210 protection and control relays for generator panels, power plants, industrial projects, utilities, EPC contractors and maintenance requirements.
For a correct quotation, buyers can share the complete relay ordering code, generator rating, CT and VT details, auxiliary supply voltage, communication requirement and quantity. For replacement enquiries, a clear photograph of the existing relay nameplate is also useful.
The exact VAMP 210 reference should be checked before ordering, as communication modules, digital inputs and outputs, auxiliary supply and other hardware options may differ between relay configurations.
