Schneider Electric Easergy MiCOM P441 High Performance Distance Protection Relay

Schneider Electric Easergy MiCOM P441 High Performance Distance Protection Relay is designed to provide fast and dependable protection for transmission and sub-transmission lines. It combines high-speed distance protection with backup protection, monitoring and control functions, making it suitable for overhead lines and underground cable networks across medium, high and extra-high voltage systems.

The MiCOM P441 provides five-zone distance protection together with directional earth fault protection and comprehensive backup functions. It is suitable for single circuit breaker applications and supports both single-pole and three-pole tripping. Built-in fault location, auto-reclose and check synchronism functions help improve fault restoration time while reducing network interruptions.

The relay integrates easily with modern digital substations through IEC 61850 communication and process bus support. Advanced teleprotection options, event recording and Ethernet redundancy make the MiCOM P441 a practical solution for utilities and industrial power systems that require reliable transmission line protection.

Specifications

• Manufacturer: Schneider Electric
• Product Family: Easergy MiCOM
• Model: MiCOM P441
• Relay Type: Numerical High Performance Distance Protection Relay
• Protection Application: Transmission and sub-transmission line protection
• Suitable For: Overhead lines and underground cables
• Distance Protection: Five-zone distance protection
• Directional Earth Fault Protection: Supported
• Backup Protection: Comprehensive backup protection
• Auto-Reclose: Supported
• Check Synchronism: Supported
• Fault Locator: Integrated
• Tripping: Single-pole and three-pole tripping
• Distance Characteristic: Quadrilateral
• Communication Interfaces: Serial and Ethernet
• Communication Protocols: IEC 61850, IEC 61850-9-2 Process Bus
• Teleprotection: InterMiCOM64 and RS232 options
• Ethernet Redundancy: PRP, RSTP and dual homing support
• Event Recording: Supported
• Mounting: Standard modular case

Features

• High-performance numerical distance protection relay.
• Five-zone distance protection for transmission and sub-transmission networks.
• Directional earth fault and backup protection functions.
• Built-in fault locator helps identify fault location quickly.
• Auto-reclose and check synchronism improve network restoration.
• Supports IEC 61850 and digital substation process bus architecture.
• Built-in teleprotection options for line protection schemes.
• Ethernet redundancy improves communication reliability.
• Event recording supports fault analysis and maintenance.
• Suitable for overhead line and underground cable protection.

Applications

• Transmission line protection
• Sub-transmission networks
• Overhead line protection
• Underground cable protection
• Utility substations
• Digital substations
• Industrial power transmission systems
• High-voltage and extra-high-voltage networks

Schneider Electric Easergy MiCOM P441 High Performance Distance Protection Relay combines fast fault detection, advanced communication and comprehensive line protection functions, making it suitable for modern transmission systems where dependable protection and quick fault clearance are essential.
