Schneider Electric PowerLogic™ A3-F6P Arc Flash Protection Relay

The Schneider Electric PowerLogic™ A3-F6P Arc Flash Protection Relay is designed to provide fast and scalable arc flash protection for low and medium-voltage switchgear. It detects arc faults using optical light sensors and sends high-speed trip commands to isolate the affected circuit before the fault can cause significant damage. Its quick response helps improve equipment protection while enhancing personnel safety.

The A3-F6P is designed for single-panel installations but can also be expanded into larger protection systems. It supports up to six optical arc sensors, allowing multiple protection zones to be monitored from one device. For larger switchgear line-ups, the relay can be connected with additional PowerLogic A3 units through the system bus, creating a flexible arc flash protection solution as the installation grows.

With a wide auxiliary supply range, multiple mounting options and straightforward configuration using rotary switches, the PowerLogic A3-F6P is suitable for both new installations and retrofit projects across industrial, commercial and utility applications.

Specifications

• Manufacturer: Schneider Electric
• Product Family: PowerLogic™ A3
• Model: A3-F6P
• Relay Type: Arc Flash Protection Relay
• Protection Application: Low and Medium-Voltage Switchgear
• Protection Technology: Optical Arc Flash Detection
• Arc Sensor Capacity: Up to 6 Optical Arc Sensors
• Protection Zones: Multi-Zone Detection
• System Expansion: Bus Connection with Other PowerLogic A3 Devices
• Auxiliary Supply Voltage: 48 VAC to 240 VAC or 48 VDC to 240 VDC
• High-Speed Trip Outputs: 2
• Relay Output: 1
• Configuration: Rotary Switches
• Mounting Options: DIN Rail or Flush Panel (with mounting frame)
• Human Machine Interface: LED Status Indicators

Features

• Fast arc flash protection for low and medium-voltage switchgear.
• Supports up to six optical arc sensors.
• Multi-zone detection for accurate fault location.
• Expandable architecture through PowerLogic A3 bus connection.
• Two high-speed trip outputs for rapid fault isolation.
• Wide auxiliary voltage range for flexible installation.
• Rotary switch configuration for quick commissioning.
• DIN rail and flush panel mounting options.
• Compact design suitable for new installations and retrofit projects.
• Reliable operation in industrial and utility environments.

Applications

• Low-voltage switchboards
• Medium-voltage switchgear
• Utility substations
• Industrial power distribution systems
• Manufacturing facilities
• Mining and mineral processing plants
• Oil and gas installations
• Data centres
• Water and wastewater treatment plants
• Critical infrastructure

The Schneider Electric PowerLogic™ A3-F6P Arc Flash Protection Relay offers a flexible and reliable solution for arc flash protection in electrical distribution systems. Its scalable design, multi-zone protection capability and fast operating response make it well suited for applications where equipment reliability and personnel safety are essential.
