ABB Motor 3-Phase squirrel cage motor IE3 4 Poles Non FLP 220-380-400 V 0.25kW Frame 71 IP 55 Foot Mounting Motor – 3GBA072320-ASKCN

• Brand : ABB Motors
• Product Name : 3-Phase squirrel cage motor
• Efficiency Class : IE3
• Poles : 4
• Phase : 3
• Protection Type : Non FLP
• Input Voltage : 220-380/400 V
• Output Power : 0.25 kW
• Ambient Temperature : 40 °C
• Frame Size : 71
• Enclosure Protection: IP55
• Mounting : Foot Mount

The ABB motor 3GBA072320-ASKCN is a high-efficiency, three-phase squirrel cage induction motor designed for general industrial applications. With a power output of 0.25 kW and a 4-pole configuration, it is well-suited for continuous-duty operations. This motor operates at voltages of 220V (Δ) or 380V/400V (Y) at 50 Hz, delivering a speed of approximately 1432–1440 rpm. The motor is built with a durable cast iron frame and features a Totally Enclosed Fan Cooled (TEFC) design with IP55 protection, making it ideal for various industrial environments. It boasts an IE3 premium efficiency rating, ensuring energy-saving performance. The 3GBA072320-ASKCN is equipped with Class F insulation and a cooling method of IC411, offering reliable operation in applications like pumps, fans, and conveyors. With a foot-mounted configuration (IMB3), it provides robust, long-lasting performance for demanding industrial tasks.
